Product Details
Place of Origin: Jinan, Shandong
Brand Name: JIURUNFA
Certification: ISO9001
Model Number: MDF Acoustic panel S77 Red Oak
Payment & Shipping Terms
Minimum Order Quantity: 1㎡
Price: $1
Packaging Details: Plastic sealed packaging
Delivery Time: 5-14 work days
Payment Terms: L/C,T/T,Western Union,MoneyGram
Supply Ability: 100000 ㎡
Production Process: |
Hot-press Forming ；Wet-mixed Cement Bonding |
Density: |
120–200 Kg/m³（PET） / 300–450 Kg/m³（Wood Wool） |
Acoustic Rating : |
NRC 0.75–0.95(Tested According To ASTM C423 Or ISO 354) |
Sound Absorption Range : |
Effective Sound Absorption At 125 Hz – 4000 Hz. |
Flammability Rating : |
Class A / B1 According To ASTM E84, EN 13501-1, GB 8624-2012 |
Thermal Conductivity : |
0.040–0.045 W/m·K |
Formaldehyde Emission: |
E0（≤0.5 Mg/L） / EN 717-1 Compliance |
Moisture Rate : |
≤ 0.8%(PET) |
Water Absorption: |
<1% Dimensional Change / Rate Of Dimensional Change |
Compressive Strength : |
≥ 120 KPa(PET) |
Tensile Strength : |
≥ 90 KPa |
Main Applications: |
Office / School / Restaurant / Hotel / Recording Studio / Home Theater / Conference Room / Medical Space / Industrial Plant |
ISO 9001: |
Worldwide |
ISO 14001: |
Worldwide |
CE Certification: |
EU |
Shelf Life: |
5-10 Years |
Installation Efficiency: |
Skilled Workers: 20-30㎡/person/day |
Installation Tool Requirements: |
Ordinary Hand Tools Are Sufficient |
Installation Accessories: |
T-shaped Keel / Mounting Adhesive / Magnetic Sticker / Hanger / Connector |
Origin: |
Jinan, Shandong |
Brand: |
JIURUNFA |
Production Process: |
Hot-press Forming ；Wet-mixed Cement Bonding |
Density: |
120–200 Kg/m³（PET） / 300–450 Kg/m³（Wood Wool） |
Acoustic Rating : |
NRC 0.75–0.95(Tested According To ASTM C423 Or ISO 354) |
Sound Absorption Range : |
Effective Sound Absorption At 125 Hz – 4000 Hz. |
Flammability Rating : |
Class A / B1 According To ASTM E84, EN 13501-1, GB 8624-2012 |
Thermal Conductivity : |
0.040–0.045 W/m·K |
Formaldehyde Emission: |
E0（≤0.5 Mg/L） / EN 717-1 Compliance |
Moisture Rate : |
≤ 0.8%(PET) |
Water Absorption: |
<1% Dimensional Change / Rate Of Dimensional Change |
Compressive Strength : |
≥ 120 KPa(PET) |
Tensile Strength : |
≥ 90 KPa |
Main Applications: |
Office / School / Restaurant / Hotel / Recording Studio / Home Theater / Conference Room / Medical Space / Industrial Plant |
ISO 9001: |
Worldwide |
ISO 14001: |
Worldwide |
CE Certification: |
EU |
Shelf Life: |
5-10 Years |
Installation Efficiency: |
Skilled Workers: 20-30㎡/person/day |
Installation Tool Requirements: |
Ordinary Hand Tools Are Sufficient |
Installation Accessories: |
T-shaped Keel / Mounting Adhesive / Magnetic Sticker / Hanger / Connector |
Origin: |
Jinan, Shandong |
Brand: |
JIURUNFA |
Acoustic Panels Product Introduction
Acoustic panels are high-performance sound-absorbing materials designed to reduce noise, echo, and reverberation in various indoor environments. Made from eco-friendly polyester fiber, foam, wood, or fabric-wrapped composites, these panels effectively enhance acoustic comfort while improving overall interior aesthetics.
Engineered with excellent sound absorption coefficients (NRC 0.8–1.0), our acoustic panels are widely used in offices, conference rooms, studios, home theaters, classrooms, hotels, gyms, and industrial noise-control areas. They minimize unwanted reflections and create clearer, more focused sound environments.
Our panels are lightweight, easy to install, and available in multiple shapes, colors, and thickness options to match diverse design requirements. With fire-resistant, moisture-resistant, and environmentally safe materials, they offer long-lasting performance and stable acoustic results.
Whether for professional sound engineering or everyday noise reduction, our acoustic panels deliver reliable, eco-friendly, and aesthetically pleasing solutions for modern interior spaces.
Acoustic Panels Product Specifications
| Item | Technical Specification |
|---|---|
| Product Name | Acoustic Panel |
| Material Composition | 100% Polyester Fiber(PET) or Wood Wool + Cement |
| Production Process | Hot-press Forming ；Wet-mixed Cement Bonding |
| Density | 120–200 kg/m³(PET) / 300–450 kg/m³(Wood Wool) |
| Acoustic Rating | NRC 0.75–0.95(Tested according to ASTM C423 or ISO 354) |
| Sound Absorption Range | Effective sound absorption at 125 Hz – 4000 Hz. |
| Flammability Rating | Class A / B1 According to ASTM E84, EN 13501-1, GB 8624-2012 |
| Thermal Conductivity | 0.040–0.045 W/m·K |
| Formaldehyde Emission | E0(≤0.5 mg/L) / EN 717-1 compliance |
| Moisture Rate | ≤ 0.8%(PET) |
| Water Absorption | <1% Dimensional Change / Rate of Dimensional Change |
| Compressive Strength | ≥ 120 kPa(PET) |
| Tensile Strength | ≥ 90 kPa |
| Surface Finishing | Plain / Grooved / Beveled Edge / Fabric Wrapped |
| Standard Sizes | 1220×2420 mm, 600×600 mm, 600×1200 mm(Customization supported) |
| Thickness | 9 mm / 12 mm / 24 mm / 25 mm / 50 mm |
| Color Options | 40–60 Color Options / 40–60 colors available (customization supported) |
| Installation | Adhesive / Aluminum Frame / Z-Clips / |
| Environmental Certifications | SGS / REACH / RoHS Available |
| Applications | Studios, Offices, Theaters, Schools, Hotels |
Acoustic Panels Features
Superior Sound Absorption Performance
Effectively reduces noise and controls echo, with a Noise Reduction Ratio (NRC) of 0.75–0.95.
Wide Frequency Absorption Range
Performs excellently across a frequency range of 125 Hz to 4000 Hz, suitable for speech, music, and general indoor acoustic treatment.
Fire Resistant
Meets Class A/B1 fire resistance standards (ASTM E84, EN 13501-1, GB 8624), ensuring enhanced safety.
Environmentally Friendly and Non-Toxic
Made from recyclable polyester fibers, low in VOCs, and with formaldehyde content meeting E0 standards, suitable for schools, offices, and homes.
Lightweight and Easy to Install
Can be mounted on walls or ceilings using adhesives, frames, or clips.
Durable and Stable
High-density materials ensure excellent impact resistance, stability, and lifespan.
Humidity and Thermal Stability: Low water absorption (<1%), maintaining stability in various indoor environments; thermal conductivity of 0.040–0.045 W/m·K.
Aesthetically pleasing and Customizable Designs: Available in 40–60 colors, various patterns, perforated or grooved finishes, and customizable shapes.
Safe and Comfortable Indoor Environment: Free of fiberglass dust, odorless, and hypoallergenic, making it ideal for public spaces, offices, and homes.
Acoustic Panels Application Cases
Client: A YouTube music cover artist in Seoul
Problem: Low-frequency buildup in the corners of the room caused the bass and kick drum in his cover videos to sound muffled, as if they were muffled.
Solution: Installed low-frequency traps vertically in the four corners of the room.
Result: The low-frequency response curve became flatter, the video audio quality was significantly improved, and the channel subscribers increased by 20,000 within 3 months.
About Us
Our Acoustic Treatment Panels are made from 100% polyester fiber (PET), with recycled materials accounting for 45-60%, truly achieving green environmental protection and a circular economy. The core advantage of the product lies in its superior acoustic performance—an NRC (noise reduction coefficient) of 0.85-1.05, effectively reducing spatial reverberation time to 0.5-0.8 seconds, significantly improving speech clarity and auditory comfort; it also meets EN 13501-1 Class B-s2,d0 international fire resistance certification, has VOC emissions ≤0.01 mg/m³, and complies with AATCC anti-mildew and antibacterial standards, balancing safety, health, and durability.
