Product Details
Place of Origin: Jinan, Shandong
Brand Name: JIURUNFA
Certification: ISO9001
Model Number: MDF Acoustic panel S77 Red Oak
Payment & Shipping Terms
Minimum Order Quantity: 1㎡
Price: $1
Packaging Details: Plastic sealed packaging
Delivery Time: 5-14 work days
Payment Terms: L/C,T/T,Western Union,
Supply Ability: 100000 ㎡
Main Function: |
Sound Absorption, Noise Reduction, Echo And Reverberation Control |
Core Materials: |
Polyester Fiber, Foam, Wood, Mineral Fiber, Fabric-wrapped Composites, Etc. |
Environmental Properties: |
Recyclable Polyester Fibers, Low VOCs, Formaldehyde Emission ≤0.05mg/m³ (E0/E1 Grade) |
Tensile Strength : |
≥ 90 KPa |
Main Applications: |
Office / School / Restaurant / Hotel / Recording Studio / Home Theater / Conference Room / Medical Space / Industrial Plant |
Color Options: |
40–60 Standard Colors, Custom Colors Available |
ISO 9001: |
Worldwide |
Shelf Life: |
5-10 Years |
Installation Efficiency: |
Skilled Workers: 20-30㎡/person/day |
Main Function: |
Sound Absorption, Noise Reduction, Echo And Reverberation Control |
Core Materials: |
Polyester Fiber, Foam, Wood, Mineral Fiber, Fabric-wrapped Composites, Etc. |
Environmental Properties: |
Recyclable Polyester Fibers, Low VOCs, Formaldehyde Emission ≤0.05mg/m³ (E0/E1 Grade) |
Tensile Strength : |
≥ 90 KPa |
Main Applications: |
Office / School / Restaurant / Hotel / Recording Studio / Home Theater / Conference Room / Medical Space / Industrial Plant |
Color Options: |
40–60 Standard Colors, Custom Colors Available |
ISO 9001: |
Worldwide |
Shelf Life: |
5-10 Years |
Installation Efficiency: |
Skilled Workers: 20-30㎡/person/day |
Acoustic Panels Product Introduction
Acoustic panels are high‑performance sound‑absorbing materials for lowering noise, echo and reverberation indoors. Constructed from eco‑friendly polyester fiber, foam, wood or fabric‑wrapped composites, they boost acoustic comfort and interior aesthetics.
Featuring an NRC of 0.8‑1.0, these panels apply to offices, meeting rooms, studios, home theaters, classrooms, hotels, gyms and industrial noise‑control zones by cutting sound reflections for clearer audio.
Lightweight and easy‑to‑install, they come in various shapes, colors and thicknesses. Fire‑resistant, moisture‑proof and non‑toxic, they maintain stable acoustic performance long‑term. Ideal for professional acoustic projects and daily noise reduction as practical, decorative and eco‑friendly interior solutions.
Acoustic Panels Product Specifications
| Item | Technical Specification |
|---|---|
| Product Name | Acoustic Panel |
| Material Composition | 100% Polyester Fiber(PET) or Wood Wool + Cement |
| Production Process | Hot-press Forming ；Wet-mixed Cement Bonding |
| Density | 120–200 kg/m³(PET) / 300–450 kg/m³(Wood Wool) |
| Acoustic Rating | NRC 0.75–0.95(Tested according to ASTM C423 or ISO 354) |
| Sound Absorption Range | Effective sound absorption at 125 Hz – 4000 Hz. |
| Flammability Rating | Class A / B1 According to ASTM E84, EN 13501-1, GB 8624-2012 |
| Thermal Conductivity | 0.040–0.045 W/m·K |
| Formaldehyde Emission | E0(≤0.5 mg/L) / EN 717-1 compliance |
| Moisture Rate | ≤ 0.8%(PET) |
| Water Absorption | <1% Dimensional Change / Rate of Dimensional Change |
| Compressive Strength | ≥ 120 kPa(PET) |
| Tensile Strength | ≥ 90 kPa |
| Surface Finishing | Plain / Grooved / Beveled Edge / Fabric Wrapped |
| Standard Sizes | 1220×2420 mm, 600×600 mm, 600×1200 mm(Customization supported) |
| Thickness | 9 mm / 12 mm / 24 mm / 25 mm / 50 mm |
| Color Options | 40–60 Color Options / 40–60 colors available (customization supported) |
| Installation | Adhesive / Aluminum Frame / Z-Clips / |
| Environmental Certifications | SGS / REACH / RoHS Available |
| Applications | Studios, Offices, Theaters, Schools, Hotels |
Acoustic Panels Features
Our acoustic panels feature NRC 0.75‑0.95 with broad 125‑4000 Hz sound absorption to reduce noise and echo. Certified Class A/B1 fire‑resistant (ASTM E84, EN 13501‑1, GB 8624), they are made of recyclable low‑VOC polyester fiber meeting E0 formaldehyde standard, fiberglass‑dust‑free, odorless and hypoallergenic. Lightweight for wall/ceiling mounting with adhesives, frames or clips. High‑density construction offers impact resistance and long service life; low water absorption (<1%) and 0.040‑0.045 W/m·K thermal conductivity ensure stable performance. Available in 40‑60 colors, diverse patterns, perforated/grooved finishes and custom shapes for offices, schools, homes and public areas.
Acoustic Panels Application Cases
Client: A Michelin-recommended restaurant in Madrid
Problem: The restaurant was very popular, but excessive interior decoration created too much noise, forcing customers to shout to chat, resulting in a lower table turnover rate.
Solution: Decorative fiberglass sound-absorbing panels were installed in the ceiling and booth partitions.
Result: The restaurant environment became elegant and quiet, customers were willing to stay longer and order more drinks, the average spending per customer increased, and positive reviews increasingly mentioned "suitable for dates."
About Us
Our Acoustic Treatment Panels are made from 100% polyester fiber (PET), with recycled materials accounting for 45-60%, truly achieving green environmental protection and a circular economy. The core advantage of the product lies in its superior acoustic performance—an NRC (noise reduction coefficient) of 0.85-1.05, effectively reducing spatial reverberation time to 0.5-0.8 seconds, significantly improving speech clarity and auditory comfort; it also meets EN 13501-1 Class B-s2,d0 international fire resistance certification, has VOC emissions ≤0.01 mg/m³, and complies with AATCC anti-mildew and antibacterial standards, balancing safety, health, and durability.
