Product Details
Place of Origin: Jinan, Shandong
Brand Name: JIURUNFA
Certification: ISO9001
Model Number: MDF Acoustic panel S77 Red Oak
Payment & Shipping Terms
Minimum Order Quantity: 1㎡
Price: $1
Packaging Details: Plastic sealed packaging
Delivery Time: 5-14 work days
Payment Terms: L/C,T/T,Western Union,
Supply Ability: 100000 ㎡
Flammability Rating : |
Class A / B1 According To ASTM E84, EN 13501-1, GB 8624-2012 |
Thermal Conductivity : |
0.040–0.045 W/m·K |
Formaldehyde Emission: |
E0（≤0.5 Mg/L） / EN 717-1 Compliance |
Product Name: |
Acoustic Panels, Decorative Acoustic Wall Panels, Polyester Acoustic Panels, Wood Slat Acoustic Panels |
Surface Finish: |
Fabric Wrapped / Natural Wood Veneer / Matte Finish / Grooved Slat / 3D Textured |
Compressive Strength : |
≥ 120 KPa(PET) |
Tensile Strength : |
≥ 90 KPa |
Sound Absorption Frequency: |
600‑5000 Hz |
Fire Rating: |
B1 Class Flame Retardant |
ISO 9001: |
Worldwide |
ISO 14001: |
Worldwide |
Shelf Life: |
5-10 Years |
Installation Efficiency: |
Skilled Workers: 20-30㎡/person/day |
Flammability Rating : |
Class A / B1 According To ASTM E84, EN 13501-1, GB 8624-2012 |
Thermal Conductivity : |
0.040–0.045 W/m·K |
Formaldehyde Emission: |
E0（≤0.5 Mg/L） / EN 717-1 Compliance |
Product Name: |
Acoustic Panels, Decorative Acoustic Wall Panels, Polyester Acoustic Panels, Wood Slat Acoustic Panels |
Surface Finish: |
Fabric Wrapped / Natural Wood Veneer / Matte Finish / Grooved Slat / 3D Textured |
Compressive Strength : |
≥ 120 KPa(PET) |
Tensile Strength : |
≥ 90 KPa |
Sound Absorption Frequency: |
600‑5000 Hz |
Fire Rating: |
B1 Class Flame Retardant |
ISO 9001: |
Worldwide |
ISO 14001: |
Worldwide |
Shelf Life: |
5-10 Years |
Installation Efficiency: |
Skilled Workers: 20-30㎡/person/day |
Product Introduction
Acoustic Panels Product Specifications
| Item | Technical Specification |
|---|---|
| Product Name | Acoustic Panel |
| Material Composition | 100% Polyester Fiber(PET) or Wood Wool + Cement |
| Production Process | Hot-press Forming ；Wet-mixed Cement Bonding |
| Density | 120–200 kg/m³(PET) / 300–450 kg/m³(Wood Wool) |
| Acoustic Rating | NRC 0.75–0.95(Tested according to ASTM C423 or ISO 354) |
| Sound Absorption Range | Effective sound absorption at 125 Hz – 4000 Hz. |
| Flammability Rating | Class A / B1 According to ASTM E84, EN 13501-1, GB 8624-2012 |
| Thermal Conductivity | 0.040–0.045 W/m·K |
| Formaldehyde Emission | E0(≤0.5 mg/L) / EN 717-1 compliance |
| Moisture Rate | ≤ 0.8%(PET) |
| Water Absorption | <1% Dimensional Change / Rate of Dimensional Change |
| Compressive Strength | ≥ 120 kPa(PET) |
| Tensile Strength | ≥ 90 kPa |
| Surface Finishing | Plain / Grooved / Beveled Edge / Fabric Wrapped |
| Standard Sizes | 1220×2420 mm, 600×600 mm, 600×1200 mm(Customization supported) |
| Thickness | 9 mm / 12 mm / 24 mm / 25 mm / 50 mm |
| Color Options | 40–60 Color Options / 40–60 colors available (customization supported) |
| Installation | Adhesive / Aluminum Frame / Z-Clips / |
| Environmental Certifications | SGS / REACH / RoHS Available |
| Applications | Studios, Offices, Theaters, Schools, Hotels |
About Us
Our Acoustic Treatment Panels are made from 100% polyester fiber (PET), with recycled materials accounting for 45-60%, truly achieving green environmental protection and a circular economy. The core advantage of the product lies in its superior acoustic performance—an NRC (noise reduction coefficient) of 0.85-1.05, effectively reducing spatial reverberation time to 0.5-0.8 seconds, significantly improving speech clarity and auditory comfort; it also meets EN 13501-1 Class B-s2,d0 international fire resistance certification, has VOC emissions ≤0.01 mg/m³, and complies with AATCC anti-mildew and antibacterial standards, balancing safety, health, and durability.
